Telecamera ColorVu Panoramica:Bullet 8MP (5120×1440) 12.5Fps. 2x CMOS, Sensore 1/1.8″ Progressive Scan, colore 0,005 Lux (F1.0, AGC ON), 0 Lux con illuminatore smart Portata 40 m, 2x Ottica fissa 4 mm, dual lens fusion technology, BLC, HLC, 3D DNR. Algoritmo di compressione H.265+, H.265, H.264+, H.264. Funzioni smart: Line crossing detection, intrusion detection, region entrance detection, region exiting detection (tecnologia ACUSENSE discriminazione uomo/veicolo), scene change detection. Luce stroboscopica e Allarme Audio. ANR, ROI. Slot per scheda SD e SD/SDHC fino a 256 GB (non fornita). Protocolli TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, Sm.P, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, ONVIF (Profile S, Profile G, Profile T), Scheda Ethernet 10/100 m, Audio: 1/1. Allarme: 1/1. Alimentazione 12 Vcc o POE 10,5 W Max, Temperatura di esercizio -30 °C ~ +60 °C, IP67. Certificazioni CE, EMC
SPECIFICHE TECNICHE
Modello | DS-2CD2T87G2P-LSU/SL(4mm) |
---|---|
Risoluzione | Panoramica: 2 x 4MP – 5120 x 1440 |
Frame rate | 12.5 fps (5120 × 1440); 20 fps (5120 × 1440) WDR OFF |
Sensore | 2 × 1/1.8″ Progressive Scan CMOS |
Sensibilità | Colore: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux con luce bianca |
Ottica | 4 mm F1.0 |
Compressione Video | H.265+/H.265/H.264+/H.264 |
Smart features | Line crossing detection, intrusion detection, region entrance detection, region exiting detection (support alarm triggered by specified target types (human and vehicle), scene change detection |
Streams | 3 |
Portata IR | 40 m (Luce bianca) |
WDR | 130 dB |
Slot SD Card | 1 slot microSD/microSDHC/microSDXC/TFcard fino a 256 GB (non fornita) |
Interfaccia di rete | 1 RJ45 10/100 Mbps self-adaptive Ethernet port |
Ingresso/Uscita audio | 1 / 1 – Microfono incorp. / Altoparlante 1 W |
Ingresso/Uscite allarme | 1 / 1 (max. 24 Vcc, 1 A) |
Interfaccia di rete | Ethernet 10/100 Mbps RJ45 |
Riscaldatore | No |
Alimentazione | 12 Vcc ± 25%, PoE(802.3 af) max. 9.5 W |
Temperatura di esercizio | -30 °C ~ +60 °C |
Grado di protezione IP | IP67 |
Peso | 1420 g |
Dimensioni | 118.6 x 105.1 x 305.4 mm |
Certificazioni | CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014 |
